FTTH Cable (ar--ftth-gyxtpy-1)
Variant image

FTTH Cable (ar--ftth-gyxtpy-1)

https://aromnetworks.com/web/image/product.template/3993/image_1920?unique=317e46d

Good mechanical and temperature performance.High strength loose tube that is hydrolysis resistant.Special tube filling compound ensure a critical protection of fiber.Crush resistance and flexibility.Inexpensive and can reduce operating costs.Two parallel steel wires ensure tensile strength.Small diameter, light weight and friendly installation.Long delivery length.

1.00 $ 1.0 CAD 1.00 $

1.00 $

Not Available For Sale

    This combination does not exist.

    Contact Us

    Terms and Conditions
    30-day money-back guarantee
    Shipping: 2-3 Business Days

    Description of FTTH Cable

    The fibers, 250μm, are positioned in a loose tube made of a high modulus plastic. The tubes are filled with a water-resistant filling compound. Two parallel steel wires are placed at the two sides of the steel tape. The cable is completed with a polyethylene (PE) sheath.


    Characteristics of FTTH Cable

    • Good mechanical and temperature performance.

    • High strength loose tube that is hydrolysis resistant.

    • Special tube filling compound ensure a critical protection of fiber.

    • Crush resistance and flexibility.

    • Inexpensive and can reduce operating costs.

    • Two parallel steel wires ensure tensile strength.

    • Small diameter, light weight and friendly installation.

    • Long delivery length.


    Optical Characteristics of FTTH Cable


    G.652

    G.655

    50/125μm

    62.5/125μm

    Attenuation

    (+20℃)

    @850nm



    ≤3.0 dB/km

    ≤3.0 dB/km

    @1300nm



    ≤1.0 dB/km

    ≤1.0 dB/km

    @1310nm

    ≤0.36 dB/km

    ≤0.40 dB/km



    @1550nm

    ≤0.22 dB/km

    ≤0.23dB/km



    Bandwidth (Class A)

    @850nm



    ≥500 MHz·km

    ≥200 MHz·km

    @1300nm



    ≥1000 MHz·km

    ≥600 MHz·km

    Numerical Aperture



    0.200±0.015NA

    0.275±0.015NA

    Cable Cut-off Wavelength λcc

    ≤1260nm

    ≤1480nm




    Technical Parameters of FTTH Cable

    Cable Type

    Fiber Count

    Cable Diameter
    mm

    Cable Weight kg/km

    Tensile Strength
    Long/Short Term N

    Crush Resistance
    Long/Short Term
    N/100mm

    Bending Radius
    Static
    /Dynamic
    mm

    GYXTPY

    1~2

    5.6

    34

    500

    500

    10D/20D

    GYXTPY

    3~6

    6.0

    38

    500

    500

    10D/20D

    GYXTPY

    7~12

    6.5

    43

    500

    500

    10D/20D

    Storage/Operating Temperature : -40℃to + 70℃
