Fiber Optic Splice closure 24cores (ar-ftth-sc24-1)

Application of Fiber Optic Splice closure 24cores

Structural features of Fiber Optic Splice closure 24cores

• It complies with the regulations of YD/T814-1996.
• The shell material is high quality engineering plastic(ABS),which is anti-aging,anti-corrosion and thunder-proof.
• The product is with the mechanical sealing structure filled with the sealing material. It can be reopened and reused without changing sealing material.
• Cable ports:4in 4out,Max capacity:192cores(single fiber)
• The 3 types of cable rings(φ12.5，φ17，φ20) are optional according to users actual needs,effectively enhancing the reliability and practicability of cable port sealing.
• The overlay structure of splice tray and the insulated grounding device make it more flexible, convenient and safer for optical cable configuration,dilatation and ground connection.
• The external components and fastening parts are all made of stainless steel,It can be reopened and reused without changing sealing material.



The key technical indexes

• Size(mm): 465 × 230×125
• Weight:2.8kg
• Fiber radius of curvature: ≥40mm
• Splice tray additional losses:≤0.01dB
• Storage fiber length:≥1.6m
• Max capacity(single fiber): 192 cores
• Working temperature: - 40℃ ~ + 70℃
• Lateral pressure: ≥2000N / 10cm
• Shock resistance:≥20N.m
